設備特點：	Equipment Features:
長壽命的管式膜可連續去除水中懸浮物與沉淀物緊湊滑架式的安裝完整的設計包含內部清洗系統自動清洗（隨洗）背脈沖裝置可使系統達到最大通量自動，無故障操作提供隨選與輔助工藝模塊 PLC自動控制	Long-life tubular membrane Suspended solids removal in the water High solid handing capacity Rack slide installation Complete design Inner cleaning system Self-cleaning(on demand) High flux Automatic, trouble-free operation Provide optional and assistant technics modules Automatic PLC control

優勢：	Advantages:
可以完全去除顆粒物質	Can remove particulate matter
對膜的運行有嚴格的保證與承諾	Strict commitment for membrane's operation
膜處理后的水，水質良好，完全不需要投加聚合物	Membrane treated water, goodquality, no need to increase polymer
完整的設計	Complete design
較傳統的工藝產出的污泥量少	Less sludge produced than the traditional process
該設備可與用戶原有的設備良好的結合使用	The device can be combined with original equipment customers
設備模塊可以按照用戶的需要添加拓展	Equipment modules can be added according to user's needs

典型應用:	Typical Applications:
金屬表面處理液中去除重金屬	Heavy metal removal in metal finishing fluids
RO預處理降SDI	Pretreatment for reverse osmosis for SDI reduction
結合石灰軟化降低硬度	Reduction of hardness with lime softening
含氟（F）廢水除氟	Fluorde removal
RO 濃水回收	Reclaim of RO reject
電鍍槽液中高濃度固體物質的去除	High solids removal in electroplating solution baths
食品飲料處理	High solids removal from completion fluids
切削液中高濃度固體物質的去除	Food and beverage processing
硅晶體研磨切片工藝切削液回用	Cutting fluids recycling in silica grinding and slicing
從焚燒爐洗滌去除水中重金屬	Heavy metal removal from incinerator scrubber water
吹式和側流式冷卻塔的過濾回收	Cooling tower blow-down recycling and/or side stream filtration
水處理系統中的鹽水再利用	Brine recycling in water treatment systems
化學、微電子、造紙工業廢水處理	Wastewater processing from the chemical, micro-electronics and pulp and paper industries

材料規格
支撐管	PVDF，HDPE
膜	PVDF
膜的名義孔徑（μm）	0.05，0.1，0.5
支撐管的名義孔徑（μm）	20，100
最大跨膜壓差（PSI）	60（1英寸管），120（1/2英寸管）
外殼材質	PVC，CPVC
組件規格（含42根1/2英寸膜管）	組件長度——72英寸組件直徑——8英寸兩端連接——8英寸外U型凹槽透過水接口——3英寸外牙槽（用于管連接）取樣口——1/4英寸NPT堵頭
組件規格（含10或13根1英寸膜管）組件規格（含37根1/2英寸膜管）	組件長度——72英寸組件直徑——6英寸兩端連接——6英寸外U型凹槽透過水接口——3英寸外牙槽（用于管連接）取樣口——1/4英寸NPT堵頭
組件規格（含4或5根1英寸膜管）	組件長度——72英寸組件直徑——4英寸兩端連接——4英寸外U型凹槽透過水接口——1.5英寸外牙槽（用于管連接）取樣口——1/4英寸NPT堵頭
組件規格（含1根1英寸膜管）	組件長度——72英寸組件直徑——2.5英寸兩端連接——1英寸螺口透過水接口——1英寸螺口取樣口——1/4英寸NPT堵頭

MATERIAL SPECIFICATIOMS
Substrate tube	Polyvinyidene Fluoride High Density Polyethylene
Membrane	Polyvinylidene Fluoride
Nominal Membrane Pore Size(μm)	0.05,0.1,0.5
Nominal Sinter Tube Pore Size(μm)	20,100
Maximum Differential Pressure (PSI)	60(1 inch tubes),120(1/2inch tubes)
Housing Materials	PVC,CPVC
Housing Connections (42×1/2inch tube)	Length -72 inches Diameter -8 inches End Connection -8inch OD Victaulic groove Permeate Ports -3 inch male socket (for tubing connection) Sample Port -1/4 inch NPT plug
Housing Connections (10 or 13×1 inch tube)	Length -72 inches Diameter -6 inches End Connections -6 inch OD Victaulic groove Permeate Ports -3 inch male socket (for tubing connection) Sample Port -1/4 inch NPT plug
Housing Connections (4 or 5×1 inch tube)	Length -72 inches Diameter -4 inches End Connections -4 inch OD Victaulic groove Permeate Ports -11/2 inch male socket (for tubing connection) Sample Port -1/4 inch NPT plug
Housing Connections (1×1 inch tube)	Length -72 inches Diameter -2.5 inches End Connections -1 inch threaded Permeate Ports -1 inch threaded Sample Port -1/4 inch NPT plug

市場領域 Application Fields	具體應用 Typical Application
金屬電鍍 Metal Electroplating	去除重金屬離子。經處理后離子濃度低于0.1ppm Heavy metal removal in metal finishing fluids, membrane filtrate less than 0.1ppm
印刷電路板 Printed Circuit Board	去除重金屬離子。經處理后離子濃度低于0.1ppm Heavy metal removal in metal finishing fluids, membrane filtrate less than 0.1ppm
0 半導體 Semi-conductor	經處理后砷化合物濃度低于0.1ppm Arsenic compounds of filtrate less than 0.1ppm 經處理后氟化合物濃度低于5ppm Fluoride compounds of filtrate less than 0.5ppm 減少硅的流失 Reduce the loss of silicon 去離子 Deionized 從鉛到錫的電鍍廢水中回收重金屬 Recycle heavy metal from electroplating wastewater of lead and tin.
回灌地下水 Underground Water Infusion	去除重金屬離子。經處理后離子濃度低于0.1ppm Remove heavy materials, filtrate less than 0.1ppm
電池制造 Battery Making	去除污水中的鉛與鎘 Lead and cadmium removal
汽車制造 Car Making	去除磷酸鹽處理工程中含有的鋅與磷酸鹽 Remove phosphate and zinc in the process of phosphate treatment.
工業一般用途 General Use of Industrial	去除焚燒清洗水中的重金屬物質 Incinerator, scrubber water treatment. 用于廢水回用中在反滲透前的預處理 RO pretreatment of wastewater recycling 在循環水中用于軟化水 Softener water in recycling water 整體的重金屬去除率達到0.1ppm Heavy metal removal, filtrate less than 0.1ppm 在沙濾工藝后代替澄清池 Replace the clarifiers after sand filters.

MATERIAL SPECIFICATIOMS j
Substrate tube	Polyvinyidene Fluoride High Density Polyethylene
Membrane	Polyvinylidene Fluoride
Nominal Membrane Pore Size(μm)	0.05,0.1,0.5
Nominal Sinter Tube Pore Size(μm)	20,100
Maximum Differential Pressure (PSI)	60(1 inch tubes),120(1/2inch tubes)
Housing Materials	PVC,CPVC
Housing Connections (42×1/2inch tube)	Length -72 inches Diameter -8 inches End Connection -8inch OD Victaulic groove Permeate Ports -3 inch male socket (for tubing connection) Sample Port -1/4 inch NPT plug
Housing Connections (10 or 13×1 inch tube)	Length -72 inches Diameter -6 inches End Connections -6 inch OD Victaulic groove Permeate Ports -3 inch male socket (for tubing connection) Sample Port -1/4 inch NPT plug
Housing Connections (4 or 5×1 inch tube)	Length -72 inches Diameter -4 inches End Connections -4 inch OD Victaulic groove Permeate Ports -11/2 inch male socket (for tubing connection) Sample Port -1/4 inch NPT plug
Housing Connections (1×1 inch tube)	Length -72 inches Diameter -2.5 inches End Connections -1 inch threaded Permeate Ports -1 inch threaded Sample Port -1/4 inch NPT plug

金屬污染物 Metal Pollutants	經TMF系統處理后，排放可達標（毫克/升） Dischanrrge Reaches Standard After Treatment of TMF System(mg/L)
銅（Cu）	0.005
鎳（Ni）	0.05
鉻（Cr）	0.05
鉛（Pb）	0.05
鎘（Cd）	0.005
鋅（Zn）	0.05
銀（Ag）	0.01
鉬（Mo）	0.1
砷（As）	0.005
氰（Cn）	0.01
金（Au）	0.1
水銀（Hg）	0.005
銠（Rh）	0.1
錫（Sn）	0.1
鈾（Pt）	0.01
鎵（Ga）	0.5
鍺（Ge）	0.5
鐵（Fe）	0.02
錳（Mn）	0.02
以上都是實際數據。如果采用不同的化學藥劑和污水處理方式，這些數據可能會有差異。

TMF產品型號
